Hydraulic Press Brake
· Press brake, also known as a brake press, is a machine tool for bending sheet and plate material, most commonly sheet metal. It forms predetermined bends by clamping the workpiece between a matching punch and die.
· Hydraulic Press Brake used for continues and complex working pieces manufacturing, advance in efficiency.
· Main Technical Parameters:
1. Nominal Force:5000KN
2. Length of Worktable:4000mm
3. No of Strokes in Idle:≥2.5 times/min
4. Distance Between Columns:3100mm
5. Depth of Throat:400mm
6. Ram Stroke:320mm
7. Max. Open Height:630mm
8. Stroke Adjustment:220mm
9. Working Pressure of Hydraulic System:26Mpa
10. Dimension Length:4200mm
Dimension Width:4115mm
Dimension Height :4760mm
11. Weight:44000Kg
-
