● Taping pitch：3-25 mm(overlap rate 33%、50%、66%)

· Pitch tolerance：≤0.3mm

· Overlap tolerance：±0.5mm

● Applicable wire range：round wire:Φ1-Φ5mm,flat wire thickness:0.8-5mm,width:3-16 mm

● Taping size：OD X Bore X Width=Φ280XΦ76X8-90mm, thickness:0.01-0.09 mm

● Taping head speed：≤1000 r.p.m

● Direction：free

● Taping motor：2kW 2000 r.p.m x 2(servo motor)

● Taping tension control：0.6kgfmDC24V magnetic powder brake + proportional tension auto controller. Auto tension compensation according to tape diameter ratio.

● Traction motor：2kW 2000 r.p.m (servo motor)

● Pay off drum：as per buyer requirement

● Take up drum：as per buyer requirement

● Total power：approx 70KW
