☀ Used for drawing round and irregular line of aluminum and aluminum alloy rod;

☀ Provide straight gear drive and separate motor drive wire drawing machine, at the same time can be selected with single or double head wire drawing machine;

☀ This machine is used to produce aluminum wires sized φ1.6-5.5mm from aluminum rods of φ9.5mm or wire φ2.0- 4.5mm from aluminum alloy rods of φ9.5mm.

☀ Each drawing ring is independently driven by a motor. Each compression ratio can be set appropriately, convenient for mold matching. Can meet a variety of grades of aluminum wire drawing.

☀ Optional: annealer can be equipped to realize aluminum alloy wire online annealing;

☀ Optional: single spooler, double automatic spooler, vertical pay-off or combination of various take-up forms;

☀ Using MMI+PLC control system, production line synchronization control, online monitoring, process parameters can be modified in the touch screen, storage, reading, simple and fast operation;

☀ Threading machine, heat exchanger, steam generator and filter are available for customer choice.

-
